| Specification |
|
| Technical Standard | Compatible with LTE, Sub6, 802.11 a/b/g/n/ac/ax |
| Frequency (EA) | EA version: n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n75/n77/n78 |
| B1/B3/B5/B7/B8/B20/B28/B32/B38/B40/B41 |
| Frequency (SA) | SA version: n2/n5/n7/n8/n12/n13/n28/n66/n38/n40/n41/n77/n78 |
| B2/B4/B5/B7/B8/B12/B13/B28/B66/B38/B40/B41/B42/B43 |
| Frequency (NA) | NA version: n2/n5/n12/n13/n14/n25/n26/n29/n30/n41/n48/n66/n71/n77/n78 |
| B2/B4/B5/B12/B13/B14/B25/B26/B29/B30/B41/B42/B43/B48/B66/B71 |
| WIFI | 2.4GHz&5.8GHz, WIFI 2*2 MIMO, 802.11 a/b/g/n/ac/ax, DBDC |
| Maximum Data Throughput | 5G SA NSA mode |
| 5G NR: (DL/UL) 3.4Gbps/900Mbps |
| LTE: (DL/UL) 1.6Gbps/200Mbps |
| Receive Diversity | Support Receive Diversity |
| MIMO | DL 4x4 MIMO |
| Chipset | Qualcomm SDX62+WCN6856 |
| Memory | Modem: 8+8Gbit |
| Power Consumption | <18W |
| Power Voltage | DC12V/1.5A |
| 4FF SIM card |
| USIM/SIM | support SIM/USIM/UIM, standard 6 PIN SIM card interface, |
| support 3V SIM card and 1.8V SIM card; internal push-pull SIM slot |
| LED | Power Indication; Wi-Fi Indication; 5G Indication LED; 4G Indication LED |
| USB | USB 2.0 |
| Antenna | Internal Antenna*11 |
| Buttons | POWER, Reset, WPS |
| 1*WAN+1*LAN |
| Ethernet | 2*1000Base automatic adaptive port (default) |
| 1*2.5Gbps + 1*1Gbps port (optional) |
| Reset | Pinhole |
| ESD | ESD Protection circuit; Contact±8KV, Air±10KV |
| HTTP | Support |
| Operating Temperature | Normal: 0°C ~ +40°C; |
| Storage Temperature | -20° C ~ +70° C |
| Humidity | 5%~ 95% |
